WTW MultiLine® Multi 3630 IDS pocket pH meter

Beschreibung

WTW MultiLine® Multi 3630 IDS pocket pH meter

The WTW MultiLine® Multi 3630 IDS pocket pH meter is a high-precision, portable meter that has been specially developed for determining pH, oxygen saturation, conductivity and other parameters. Thanks to its compact dimensions and robust design, it is ideal for use in laboratories, environmental monitoring and industrial applications. Compared to similar devices such as the WTW MultiLine® Multi 3620 IDS SET multiparameter pocket meter, the Multi 3630 IDS offers enhanced functionality and user-friendliness.

Technical data and functions

The MultiLine® Multi 3630 IDS is equipped with a backlit LCD color display that allows clear and easy reading of the measured values. It supports multiple parameters including:

• pH and mV
• Oxygen (saturation, concentration, partial pressure, BOD)
• Conductivity (resistivity, salinity, TDS)
• temperature
• turbidity
• Depth (with MPP 930 IDS)

The measuring range depends on the IDS sensor used, which gives the device a high degree of flexibility. It has three measuring channels and can store up to 10,000 data records automatically. Manual storage comprises up to 500 data records. Data is transferred via mini USB-B and USB-A interfaces, which also allow the connection of USB sticks and selected printers.

Robust design and easy handling

The device is protected to IP67, which means that it is dustproof and protected against temporary immersion in water. This makes it particularly suitable for use in harsh environments. Power is supplied via a mains adapter with charging function, four NiMH rechargeable batteries (AA type) or USB. The dimensions of 180 mm height, 80 mm width and 55 mm depth make the device compact and easy to transport.

Areas of application

The WTW MultiLine® Multi 3630 IDS pocket pH meter is used in various areas:

• Laboratory analysis:ideal for precise pH measurements and other parameters in chemical and biological laboratories.
• Environmental monitoring:Suitable for monitoring water quality in rivers, lakes and other bodies of water.
• Industrial applications:Useful in the food and beverage industry, pharmaceutical industry and other industrial processes that require accurate pH and conductivity measurements.

Certifications and standards

The device complies with current industry standards and is IP67 certified. This ensures high reliability and durability even under demanding conditions.

FAQs

How is the WTW MultiLine® Multi 3630 IDS pocket pH meter calibrated?

The device has an automatic calibration function that simplifies the calibration process. Detailed instructions can be found in the instructions for use.

Which sensors are compatible with the MultiLine® Multi 3630 IDS?

The device is compatible with a wide range of IDS sensors designed for different measurement parameters. A complete list of compatible sensors can be found in the operating instructions.

Can the device be used in the field?

Yes, thanks to its robust design and IP67 certification, the MultiLine® Multi 3630 IDS is ideal for use in the field.

How is the data stored and transmitted?

The data can be saved manually or automatically and transferred to a computer or USB stick via the USB interfaces.

Conclusion

The WTW MultiLine® Multi 3630 IDS pocket pH meter is a versatile and robust measuring device that is suitable for a wide range of applications. With its high precision, ease of use and robust design, it is an excellent choice for laboratory and field applications. Similar devices such as the WTW MultiLine® Multi 3510 IDS KS1 multiparameter pocket meter also offer high functionality, but with different specifications and applications.
