Swing-out rotor 32 x1.5/2.0 ml for 4-16, 6-16

Beschreibung

Swing-out rotor 32 x1.5/2.0 ml for 4-16, 6-16

The 32 x 1.5/2.0 ml swing-out rotor for the Sigma 4-16 and 6-16 centrifuge models is a highly specialized rotor designed for efficient centrifugation of reaction tubes. With its ability to process up to 32 tubes simultaneously, this rotor offers outstanding performance and versatility for laboratories requiring high sample capacity and variety. Compared to similar products, such as the Hettich 4-place 1494 swing-out rotor for benchtop centrifuges, the Sigma rotor is superior due to its higher capacity and flexibility.

Technical details and advantages

The 32 x 1.5/2.0 ml swing-out rotor is specially designed for the Sigma 4-16 and 6-16 models and offers the following technical specifications:

• Maximum speed:
  • Sigma 4-16S: 12,000 rpm
  • Sigma 4-16KS: 13,200 rpm
  • Sigma 6-16S: 12,000 rpm
  • Sigma 6-16KS: 13,200 rpm
• Maximum RZB (relative centrifugal acceleration):
  • Sigma 4-16S: 13,523 x g
  • Sigma 4-16KS: 16,363 x g
  • Sigma 6-16S: 13,523 x g
  • Sigma 6-16KS: 16.363 x g

The rotor is equipped with four sets of buckets and has aluminum hermetic lids to ensure safe and contamination-free centrifugation. These features make it ideal for applications where high sample integrity and safety are required.

Certifications and standards

The 32 x 1.5/2.0 ml swing-out rotor meets all relevant safety and quality standards, including CE marking and ISO certifications. These certifications guarantee that the rotor meets the highest safety and performance requirements.

Application examples

This rotor is particularly suitable for:

• Molecular biology applications: Ideal for centrifugation of DNA, RNA and protein samples in 1.5-2.0 ml reaction tubes.
• Clinical diagnostics: Efficient processing of blood and urine samples for diagnostic tests.
• Pharmaceutical research: Centrifugation of samples for the analysis of active ingredients and metabolites.

FAQs

Which centrifuge models are compatible with this rotor?

The rotor is compatible with Sigma centrifuge models 4-16 and 6-16, including the 4-16S, 4-16KS, 6-16S and 6-16KS variants.

How many samples can be centrifuged simultaneously?

The rotor can centrifuge up to 32 reaction tubes with a volume of 1.5 to 2.0 ml simultaneously.

What is the maximum speed that can be achieved?

The maximum speed varies depending on the centrifuge model:

• Sigma 4-16S and 6-16S: 12,000 rpm
• Sigma 4-16KS and 6-16KS: 13,200 rpm

Are the hermetic lids replaceable?

Yes, the aluminum hermetic lids are interchangeable and can be replaced if necessary.

Conclusion

The 32 x 1.5/2.0 ml swing-out rotor for Sigma centrifuge models 4-16 and 6-16 offers an excellent combination of high capacity, flexibility and safety. With its robust technical specifications and adherence to strict quality standards, it is the ideal choice for laboratories that require reliable and efficient centrifugation.
