MACHEREY-NAGEL Thermoblock NANOCOLOR VARIO C2
The MACHEREY-NAGEL thermoblock NANOCOLOR VARIO C2 is a sophisticated block thermostat specially developed for chemical-analytical digestion. With its robust design and precise temperature control, it is ideal for use in microbiological, histological, clinical, industrial and environmental laboratories. The VARIO C2 offers reliable performance and premium quality, making it a preferred choice over similar products on the market. Similar to the MACHEREY-NAGEL thermoblock NANOCOLOR VARIO HC, the VARIO C2 offers high flexibility and ease of use.
Main features and advantages
The NANOCOLOR VARIO C2 is characterized by a variety of features that make it an indispensable device in any laboratory:
- Robust construction: Durable and reliable, ideal for daily use.
- High user-friendliness: Easy operation via a backlit, color LCD touchscreen.
- Temperature stability: Precise temperature control with a range of 40 to 160 °C.
- Fast heat-up time: Reaches 160 °C in just 10 minutes.
- Individual programs: Five pre-programmed temperatures and seven additional free program slots.
- Safety functions: Replaceable safety covers, lockable protective hoods and over-temperature protection.
- USB interfaces: For easy data transfer and updates.
Technical data
- Thermostat type: Block thermostat
- Temperature range: 40 – 160 °C (increment 1 °C)
- Temperature stability: ±1 °C (according to DIN, EN, ISO and EPA methods)
- Heating time: From 20 °C to 160 °C within 10 minutes
- Heating times: Four pre-programmed heating times (30 min, 60 min, 120 min, continuous) and eight additional free program slots
- Time range: 0h:01 – 9h:59 min (increment 0h:01 min)
- Interfaces: Bidirectional serial RS 232, USB A (master) and USB B (slave)
- Power supply: 110 – 230 V~, 50 / 60 Hz
- Power consumption: 125 / 250 VA
- Dimensions (W x D x H): 169 x 282 x 146 mm
- Weight: approx. 2.0 kg
- Test mark: CE
Certifications and standards
The NANOCOLOR VARIO C2 complies with the following directives:
- 2006/95/EC – Low Voltage Directive
- 2004/108/EC – EMC Directive
Application examples
The NANOCOLOR VARIO C2 is versatile and suitable for a wide range of applications, including
- COD according to DIN ISO 15705: 148 °C for 120 minutes
- Rapid COD: 160 °C for 30 minutes
- TOC: 120 °C for 120 minutes
- Totalnitrogen: 120 °C for 30 minutes
- Total phosphorus: 120 °C for 30 minutes
- Organic acids: 100 °C for 10 minutes
- Total metals (cadmium, chromium, iron, cobalt, copper, nickel, zinc): 120 °C for 30 minutes
- AOX: 120 °C for 30 minutes
- Hydrocarbons: 148 °C for 120 minutes
FAQs
How is the NANOCOLOR VARIO C2 operated?
It is operated via a backlit, color LCD touchscreen with display menu navigation.
What safety functions does the NANOCOLOR VARIO C2 offer?
The thermoblock has replaceable safety covers, lockable protective hoods and overtemperature protection.
Can the NANOCOLOR VARIO C2 be calibrated?
Yes, with the NANOCOLOR T-Set (not included in the scope of delivery) there is the option of fully automatic calibration and creation of a test certificate in accordance with DWA-A 704.
Conclusion
The MACHEREY-NAGEL thermoblock NANOCOLOR VARIO C2 is a versatile and reliable block thermostat that is characterized by its robust design, precise temperature control and high level of user-friendliness. It is ideal for a wide range of laboratory applications and offers numerous safety functions and individual program settings. Comparisons such as GRANT QBA series dry block thermostats show that the VARIO C2 is an excellent choice for demanding laboratory environments.
| Operation: | heating |
| Thermostat Temperature max.: | +160°C |
| Type of thermostate: | block thermostat |
| Shipping weight: | 2,80 kg |
| Item weight: | 2,80 kg |
| Instrument: | NANOCOLOR VARIO C2 |
| Type: | Programmable heating blocks for chemical-analytical digestions with 12 holes / for test tubes with 16 mm OD (outer diameter) / integrated protective lids |
| Display: | Coloured, backlit LCD touch screen |
| Operation: | Display menu guidance via touch screen |
| Temperatures: | 5 pre-programmed temperatures: 70 / 100 / 120 / 148 / 160 °C 7 free memory locations for individual temperature settings |
| Temperature range: | 40 – 160 °C (1 °C increments) |
| Temperature stability: | +1 °C (according to DIN, EN, ISO and EPA methods) |
| Warm-up time: | from 20 °C to 160 °C within 10 minutes |
| Heating times: | 4 pre-programmed heating times: 30 min / 60 min / 120 min / cont. 8 free memory locations for individual heating times |
| Time range: | 0h:01min – 9h:59 min (increments 0h:01 min) |
| Safety: | Replaceable safety covers as contact protection Lockable protective lids Overheating protection |
| Interfaces: | Bidirectional serial RS 232, USB A (master) and USB B (slave) |
| Analytical quality control: | With NANOCOLOR T-Set (Not included in the delivery.) optional fully automatic calibration and preparation of test certificates for instrument control and monitoring according to ISO 9001) |
| Update: | Via internet and USB stick |
| Power supply: | 110 – 230 V~, 50 / 60 Hz |
| Power consumption: | 125 / 250 VA |
| Dimensions (B x T x H): | 169 x 282 x 146 mm |
| Weight: | approx. 2.0 kg |
| Marking: | CE |
These instruments conform to the following directives:
– 2006/95/EC – Low-Voltage Directive
– 2004/108/EC – EMV Directive
| Suitable for all NANOCOLOR digestion methods | ||
| Application | Temperature | Time |
| COD (DIN ISO 15705) | 148 °C | 120 min |
| High-speed COD | 160 °C | 30 min |
| TOC | 120 °C | 120 min |
| total-Nitrogen | 120 °C | 30 min |
| vtotal-Phosphorous | 120 °C | 30 min |
| Organic acids | 100 °C | 10 min |
| total-Metals (Cadmium, Chromate, Iron, Cobalt, Copper, Nickel, Zinc) | 120 °C | 30 min |
| AOX | 120 °C | 30 min |
| Hydrocarbons | 148 °C | 120 min |
| Programmable, user-defined programs | 40 – 160 °C | 0h:01min – 9h:59min |
