KNF rotary evaporator RC 600

The KNFrotary evaporator RC 600is an indispensable laboratory device that is mainly used for distillation tasks, the evaporation and processing of solvents and liquid substances. Thanks to its robust and compact design and user-friendly operation, this model is particularly suitable for use in universities and research facilities. Compared to similar products such as the KNF rotary evaporator RC 900, the RC 600 offers an excellent combination of safety, efficiency and ease of use.

Features and advantages

The KNF RC 600 is characterized by its robust construction and compact size, making it ideal for laboratories with limited space. The central control unit allows easy control of all functions and the cordless heating bath provides added convenience. Other benefits include:

• Easy operation: even novice professionals can operate the rotary evaporator quickly and safely.
• Safe operation: The flask is easy to change and the device meets all safety requirements for use in practical laboratories.
• Compact design: With its compact dimensions, the RC 600 takes up very little space in the laboratory.

Technical data

• Dimensions (W x H x D): 487 mm x 823 mm x 453 mm
• Weight: 9.1 kg
• Mains voltage: 100 – 127 V / 200 – 240 V
• Frequency: 50/60 Hz
• Heating power: 1300 W
• Total output: max. 1500 W
• Power consumption: 13 A / 6.5 A
• Protection class: IP 20
• Heating temperature: 20 °C to 180 °C
• Permissiblepressure: up to 3 bar
• Permissibletemperature: -15 °C to +20 °C
• Cooled surface: 1230 cm²
• Evaporator flask size: 50 ml to 3000 ml
• Speed: 25 to 250 rpm
• Stroke: 150 mm
• Stroke speed: 38 mm/s
• USB connection: USB type B

Certifications and standards

The KNF RC 600 complies with the safety regulations of Directives 2004/108/EC, 2006/42/EC and 2011/65/EU. It also complies with the standards DIN EN 61010-1, DIN EN 61010-2-010 and DIN EN 61326-1. These certifications ensure safe and reliable operation in the laboratory environment.

Application examples

The KNF rotary evaporator RC 600 is ideal for use in chemical, pharmaceutical and biological laboratories. Typical applications include:

• Distillation: separation of solvents and substances.
• Drying: Removal of solvents from samples.
• Recovery: Recovery of solvents for reuse.
• Extraction: Isolation of specific components from mixtures.

FAQs

How do I change the flask in the KNF RC 600?

Changing the flask is straightforward and safe. Make sure that the appliance is switched off and has cooled down before changing the flask.

What safety precautions must be observed when operating the RC 600?

The rotary evaporator should always be operated under a hood or protective cover. Avoid use in damp environments and protect the appliance from rain, splashing, splashing and dripping water.

Can the RC 600 also be operated by beginners?

Yes, the simple operation and user-friendly central control unit make the RC 600 ideal for young professionals and students.

Conclusion

The KNF rotary evaporator RC 600 is a versatile and reliable laboratory device that is characterized by its robust design, simple operation and high level of safety. With its extensive technical data and certifications, it is the ideal choice for chemical, pharmaceutical and biological laboratories. Similarly equipped products such as the Heidolph Hei-VAP Expert Control Package Automatic Evaporation Plus also offer excellent performance, but the RC 600 impresses with its compact design and user-friendliness.
