Heidolph MR Plug & Play Multi-Well Hei-Standard Magnetic Stirrer
The Heidolph MR Plug & Play Multi-Well Hei-Standard Magnetic Stirrer is a high performance laboratory device specifically designed for reliable stirring tasks. With its robust construction and a variety of features, this magnetic stirrer is ideal for use in demanding laboratory environments. Compared to similar products such as the Heidolph MR Hei-Standard magnetic stirrer, the MR Plug & Play Multi-Well Hei-Standard offers enhanced functionality and ease of use.
Key features and benefits
The Heidolph MR Plug & Play Multi-Well Hei-Standard magnetic stirrer is characterized by the following main features:
- Stainless steel or porcelain stirring plate: these materials offer high resistance to chemicals and mechanical stress.
- Robust construction: Durability and reliability are guaranteed.
- Smooth-starting motor: Prevents liquids from splashing and ensures even stirring.
- Strong magnetic field: Enables stirring of large volumes of up to 20 liters.
- High stirring force: Ideal for viscous media.
- Digital display with illumination: For simple and precise control.
- Individual regulation of the stirring speed: Adaptable to different applications.
- Lock mode: Prevents unintentional changes to settings.
- Temperature sensor: For precise temperature control.
- Rapid warm-up times: Efficient working thanks to rapid heating.
Technical data
- Stirring volume: Maximum 20 liters
- Stirring positions: Single speed
- Speed range: 30 to 1400 rpm
- Heating power: 800 W
- Temperature range of heating plate: 20 – 300 °C
- Temperature range ofmedium: Maximum 250 °C
- Temperature setting accuracy: ±5 °C
- Control accuracy with sensor in themedium: ±1 °C
- Material of the stirring plate: Kera-Disk® Silumin ceramicized
- Protection class: IP 32
- Dimensions (W x H x D): 173 x 94 x 277 mm
- Weight: 2.9 kg
Certifications and standards
The Heidolph MR Plug & Play Multi-Well Hei-Standard magnetic stirrer is CE-certified and meets the requirements of DIN EN 60529 protection class IP 32. The device also has product liability insurance (PL Insurance) and a certificate for traceability, which guarantees the highest safety standards.
Application examples
This magnetic stirrer is ideal for a wide range of applications in chemical, biological and pharmaceutical laboratories:
- Chemical synthesis: stirring reaction mixtures at controlled temperatures.
- Biotechnology: Homogenization of cell cultures and biological samples.
- Pharmaceutical research: preparation of solutions and suspensions.
- Analytical chemistry: preparation of samples for analysis.
FAQs
How is the temperature controlled?
The temperature is controlled by a micro-controller, which enables precise control of the heating plate and the medium. An external temperature sensor (EKT Hei-Con) can be connected to measure and control the temperature directly in the medium.
What safety functions are integrated?
The magnetic stirrer has an independent safety circuit that switches off the heating plate in the event of overheating. There is also a sensor breakage protection for the measuring sensor, which deactivates the heating if the sensor is defective.
Can the magnetic stirrer be used for viscous media?
Yes, the Heidolph MR Plug & Play Multi-Well Hei-Standard magnetic stirrer is suitable for viscous media thanks to its high stirring force and strong magnetic field.
Conclusion
The Heidolph MR Plug & Play Multi-Well Hei-Standard magnetic stirrer is a versatile and reliable device for demanding stirring tasks in laboratories. With its numerous functions and safety features, it offers excellent performance and user-friendliness. For further information and advice, please contact our competent customer service team at any time.
| Width (magnetic stirrer, agitator): | 173 mm |
| Speed range max. (stirrer): | 1400 rpm |
| Speed range min (stirrer): | 30 rpm |
| Heating: | with hot plate |
| Height (magnetic stirrer, agitator): | 94 mm |
| Material (plate): | silumin with ceramic coating |
| Model of stirrer: | magnetic stirrer |
| Stirring positions: | one place |
| Stirring volume: | 20 l |
| Protection category: | IP 32 |
| Controller: | internal |
| Temperature range: | 0°C up to +40°C (80% humidity) |
| Depth (magnetic stirrer, agitator): | 277 mm |
| Shipping weight: | 10,00 kg |
| Item weight: | 10,00 kg |
| Model | MR Hei-Standard |
| Speed, max. (rpm) | 1.400 |
| Speed accuracy (%) | ±2 |
| Heating power (W) | 800 |
| Hotplate temperature (°C) | 20 – 300 |
| Medium temperature, max. (°C) | 250 |
| Accuracy temperature setting (°C) | ±5 |
| External temperature sensor | EKT Hei-Con |
| Temperature accuracy with external temperature sensor (°C) | ±1 |
| Sensor breakage protection | with EKT Hei-Con |
| Temperature control | Micro controller |
| Temperature accuracy hotplate (°C) | ±5 |
| Safety circuit hotplate (°C) | 25 °C over hotplate temperature |
| Stirring capacity, max. (H2O) (l) | 20 |
| Load, max. (kg) | 25 |
| Power consumption (W) | 820 |
| Permissible ambient temperature (°C) | 0 – 40 |
| Max. relative humidity (%) | 80 |
| Plate diameter (mm) | ø 145 |
| Plate material | Kera-Disk® (Silumin with ceramic coating) |
| Weight (kg) | 2.9 |
| Dimensions (l x w x h) (mm) | 173 x 277 x 94 |
| Protection class (DIN EN 60529) | IP 32 |
