ebro core thermometer TFX 410-1 with probe TPX 400-150

Beschreibung

ebro core thermometer TFX 410-1 with probe TPX 400-150

The core thermometer from ebro is a versatile measuring device that is particularly suitable for the precise measurement of core temperatures in the food industry, commercial kitchens and pharmaceutical laboratories. Thanks to its pointed stainless steel probe and robust workmanship, it offers particularly high measuring accuracy and durability compared to other thermometers on the market. Similar features to the [ebro TTX 110] make it clear that this is a reliable option when safety and measuring precision are paramount. The device also impresses with practical additional functions such as a shock-resistant design and a replaceable battery compartment.

Reliable measurements and sophisticated design

The hand-held measuring device is compact, waterproof in accordance with IP67 and equipped with a PT 1000 sensor, which ensures high accuracy in the temperature range from -50 °C to +300 °C. The TPX 400-150 sensor model supplied even covers measurements up to +400 °C, making the device suitable for particularly demanding applications. Unlike other thermometers, the probe is also connected to a 150 cm long silicone cable, which enables flexible and safe handling when measuring. Similarly equipped products such as the [ebro TLC 730] underline the reliable quality of the ebro brand.

Of particular note is the 3-point factory calibration, which means that the device also meets strict quality requirements and can be easily integrated into existing HACCP concepts. In addition, the robust and impact-resistant design of the housing ensures a long service life, even with frequent use in harsh environments. In this way, the results remain reliable even under extreme conditions.

– Shock-resistant housing
– Protection class IP67
– Measurement results with an accuracy of ±0.3 °C (device with probe)
– Measuring range -50 °C to +300 °C (device), probe up to +400 °C
– PT 1000 sensor for exact measurement results
– 3-point factory calibration including certificate
– Compact format: 109 x 54 x 22 mm (without probe)

The pointed probe itself (TPX 400-150) is made of stainless steel and, thanks to a needle length of 120 mm, enables quick and deep penetration into the material to be measured, such as meat or other food samples. The silicone cable is easy to stow away and protects users from burns when measuring in hot environments. For this purpose, the working temperature of the handle is designed for up to +120 °C, while the tip itself can measure temperatures of up to +400 °C. This core thermometer is therefore ideal for monitoring frying and cooking processes in the catering industry or temperature samples in sterility-sensitive laboratory areas, for example.

Examples of use

1. Use in commercial kitchens: Monitoring the core temperature of meat, fish or sauces to achieve the prescribed cooking level and ensure food safety.
2. Use in butcher’s shops: Precise temperature control in the production of sausage and meat products to maintain ideal hygiene standards.
3. Food packaging and transportation: control of the cold chain and verification that vacuum-packed foodstuffs maintain the prescribed storage temperatures
4. Pharmaceutical laboratories: Measuring the temperature in incubators or during sample preparation, where exact temperature data is required for documentation purposes and safety standards.

Frequently asked questions

What is the maximum operating temperature of the sensor?

The sensor is designed for up to +400 °C. However, the handle should not exceed 120 °C to avoid damage and to obtain precise measurement data.

How can the device be cleaned

?

Due to the IP67 protection class, the thermometer can be carefully held under running water. It is important not to bend the sensor too much and only use suitable disinfectants that are designed for stainless steel surfaces.

Does the device need to be calibrated regularly?

The 3-point factory calibration enables a high basic accuracy. However, to ensure reliable measurement results in the long term, it is advisable to check the device regularly in accordance with internal quality specifications and recalibrate it if necessary.

What power supply is required?

The thermometer is powered by a replaceable 3 V lithium button cell. With normal use, a long operating time is ensured before the button cell needs to be replaced.

Is a measured value resolution in 0.1 °C useful?

Yes, the device displays measured values in 0.1 °C increments. This level of detail is particularly important in areas where precise temperature ranges must be maintained (e.g. food processing, laboratory).

Conclusion

With its stable construction, high measuring accuracy and wide temperature range, this core thermometer is ideal for professional users in the kitchen, laboratory and production. The pointed probe and the extended measuring range up to +400 °C ensure that even extremely demanding tasks can be mastered effortlessly. The 3-point factory calibration, impact-resistant design and waterproof housing make the device a reliable companion for recording precise and reproducible temperature data at all times.
