BioSan TS-DW Thermo shaker for Deep Well plates

Beschreibung

BioSan TS-DW thermal shaker for deep well plates

The BioSan TS-DW Thermal Shaker for Deep Well Plates is a sophisticated laboratory device specifically designed for shaking and tempering deep well plates. This device integrates the functions of an incubator, plate shaker and thermal shaker in a single system. Thanks to BioSan’s patented dual-sided microplate heater, precise temperature control is ensured, making it a preferred choice for many laboratory applications. Similar to the BioSan TS-100 thermal shaker, the TS-DW provides reliable and uniform temperature distribution.

Key features and benefits

The BioSan TS-DW thermal shaker offers a variety of features that make it an indispensable tool in modern laboratories:

• Multifunctionality: integrates incubator, plate shaker and thermal shaker in one device.
• Patented two-sided microplate heating: Ensures a precise match between the set and actual temperature in the plate wells.
• Gentle to intensive shaking: Allows the shaking intensity to be adjusted as required.
• Rotation speed regulation: Stable and precise control of the rotation speed.
• Even rotation amplitude: Ensures consistent results with every application.
• Adjustable operating time: Automatic stop of platform movement after the set time has elapsed.
• LCD display: Shows the set and current temperature as well as the operating time.

Technical data

• Temperature range: +25°C to +100°C
• Temperature control range: 5°C above ambient temperature to +100°C
• Temperature accuracy at 37°C: ±0.1°C
• Speed range: 250 – 1400 rpm
• Orbit diameter: 2 mm
• External dimensions (W x D x H): 205 x 230 x 130 mm
• Weight: 3.2 kg
• Power supply: Input AC 100-240 V 50/60 Hz; Output DC 12 V
• Power consumption: 12 V, 4.8 A / 58 W
• Timer: 1 min – 96 h (1 min steps)

Certifications and standards

The BioSan TS-DW thermal shaker meets all relevant safety and quality standards required in laboratory environments. This includes CE certifications and other industry-specific standards.

Application examples

The BioSan TS-DW thermal shaker is versatile and suitable for a wide range of applications in various scientific disciplines:

• Cytochemistry: ideal for in-situ reactions.
• Immunochemistry: Perfect for immuno-fermentative reactions.
• Biochemistry: Suitable for enzyme and protein analysis.
• Molecular biology: Ideal for extracting nucleic acids.

FAQs

How accurate is the temperature control of the BioSan TS-DW thermal shaker?

The temperature accuracy at 37°C is ±0.1°C, which enables very precise temperature control.

Can the BioSan TS-DW thermal shaker be used for other plate formats?

The TS-DW is specially designed for deep well plates. For other plate formats such as microtiter plates, the BioSan PST-60HL thermal shaker could be a suitable alternative.

Is the BioSan TS-DW thermal shaker easy to use?

Yes, the device has a user-friendly LCD display and intuitive controls that make it easy to set and monitor the operating parameters.

Conclusion

The BioSan TS-DW thermal shaker for deep well plates is a powerful and versatile device that no modern laboratory should be without. With its precise temperature control, versatility and user-friendly operation, it offers an excellent solution for a wide range of laboratory applications. Similar to the BioSan PST-100HL plate shaker, the TS-DW offers reliable and efficient performance to meet the needs of demanding laboratory environments.
